Grader Roma 500 extensible

Graders driven type MONTEFIORI ROMA 500 EXTENSIBLE With telescopic blade 3 meters to 5 meters in trim variable working for tractors with power from 280/350 horses FRAME DESIGNED BUILT AND CALCULATED UNTIL 500 HORSES

Information data:

Graders towed with predisposizone on command LASER or GPS Built with articulated steering cassonato gooseneck.

Technical specifications

  • HP 200/330 Power
  • Width trim work blade from 3 to 5 m.
  • wheels width in trim work up to a maximum of 4.60 m
  • Overall dimensions in road trim m. 3.20
  • M height of the blade m. 1.20
  • Overall length m. 5.90
  • Overall height m. 3.20
  • Weight Kg. 3800
  • Wheel type 11.80/15.3 n° 6

Videos and tutorials

Agriculture line

Professional Products for leveling of types of soil.

Line of lifting products

Industrial lifting systems for all the needed works.
